Speaker cabinet maker in delhi ncr

Wharfedale Evo 4.2

Kumars

New Member
Joined
Nov 16, 2017
Messages
7
Points
3
Location
Gurugram
Hello to all forum members
I am Sushil from gurgaon.I am looking for a speaker cabinet that can acoomodate 6.5 inch woofer , a matching mid range driver and tweeter.I have searched a few places in Delhi and NCR but could not find a carpenter or speaker cabinet builder .suggestions needed .


stefan

Active Member
Joined
Apr 19, 2017
Messages
103
Points
28
Location
Goa
Lol, do it yourself, if you have the plans it's quite easy and can be accomplished with the usual tools guys have.


Kumars

New Member
Joined
Nov 16, 2017
Messages
7
Points
3
Location
Gurugram
I don't have the power tools like circular saw etc .I also lack the skills to use these tools .


rajesh srinivas

Active Member
Joined
May 30, 2015
Messages
377
Points
28
Location
hubli (karnataka)
Not an easy task as sadik says,since he himself has gone through the process,me too doing the boxes for my 7.1ch setup,,it requires at least minimum tools like circular saw,router,L square,hand power drill machine,and ofcourse the art of measuring things,aligning them properly and also lot of time devotion...

Little bit of misjudgement then the whole process of setup is out of order.

I am not discouraging you,if you have the right carpentry skills then go ahead or else its a no no ...

thanks
rajesh


stefan

Active Member
Joined
Apr 19, 2017
Messages
103
Points
28
Location
Goa
There's an old saying in carpentry, measure twice cut once. Honestly you don't need many tools. A circular saw (with depth and angle adjustment) with a finishing blade, a straight edge, clamps, worktable, jigsaw or router and jig (the jesper jig is a worthwhile investment, especially if you progress to more complex designs, one time investment), drill and ideally either an electric screw driver or cordless, carpentry set square, glue, screws (either Phillips or pozi-drive head), measuring tape and pencil, you'll also need something to rebate the screw heads, I forget what it's called. A good quality hole cuter set can be useful, a set of wood twists and spade bits is also worthwhile, now you'll be able to breeze through most plans, if you're doing some of Troels designs you'll need some other tools or router bits.

Most ply and MDF shops will be able to do your cutting for you, mark your cuts first and do a small test cut to see how much material you lose, so the cuts can be accurate, work in millimeters it's so much easier than calculating fractions of inches.


Aniket

Well-Known Member
Joined
Dec 24, 2013
Messages
252
Points
63
Location
Delhi
there are some carpenters in Gurugram who can build the complete box along with paint. i got some boxes made from a shop on pataudi road i think around 3-4 years ago.

now i get my mdf panels cut at a cnc shop in Delhi and i fix them together myself.

Regards,
Aniket


Kumars

New Member
Joined
Nov 16, 2017
Messages
7
Points
3
Location
Gurugram
Thanks Aniket for the info.Can you give me the address of the shops on pataudi road and in Delhi.


Aniket

Well-Known Member
Joined
Dec 24, 2013
Messages
252
Points
63
Location
Delhi
the shop name is Durga Furniture on Pataudi Road. comes on the left side of road after crossing Pataudi Chowk.
in Delhi, Kirti Nagar is the hub for wood works.

Regards,
Aniket


sonus

Member
Joined
Oct 10, 2017
Messages
42
Points
8
Location
Ludhiana
the shop name is Durga Furniture on Pataudi Road. comes on the left side of road after crossing Pataudi Chowk.
in Delhi, Kirti Nagar is the hub for wood works.

Regards,
Aniket

Aniket, what materials have you used in your builds? and which ones would you recommend?


Aniket

Well-Known Member
Joined
Dec 24, 2013
Messages
252
Points
63
Location
Delhi
I have used mdf - 11, 16.5, 18.5, 25mm and ply - 11, 19mm. Russian birch plywood is also available in Delhi.
I recommend using mdf for small bookshelfs and floorstanders with 5-12" drivers. Mdf is easier to cut and finish-easy to DIY. For anything above 12" use ply or birch ply.
Although, each material has its own sonic properties and character, It depends on the kind of application where and how it is used.

Regards,
Aniket


sonus

Member
Joined
Oct 10, 2017
Messages
42
Points
8
Location
Ludhiana
I have used mdf - 11, 16.5, 18.5, 25mm and ply - 11, 19mm. Russian birch plywood is also available in Delhi.
I recommend using mdf for small bookshelfs and floorstanders with 5-12" drivers. Mdf is easier to cut and finish-easy to DIY. For anything above 12" use ply or birch ply.
Although, each material has its own sonic properties and character, It depends on the kind of application where and how it is used.

Regards,
Aniket

Thanks for the info! Iread some BBC Audio tech papers, and in their testing, MDF was seen as one of the best. My friends confirm the same, be it DIY speaker enclosures or headphone cups.

BTW, I also saw that you made nice speakers from that Blaupunkt car speakers.

@Kumars - sorry for hacking the conversation.


NeoG

New Member
Joined
Jan 18, 2018
Messages
3
Points
3
Location
New Delhi
Hello Aniket... you mentioned getting your MDF/ply cut at a CNC shop in Delhi. Is it Durga Furniture that you mention? Otherwise, can you please give me the address?
Best,
Kingshuk


Aniket

Well-Known Member
Joined
Dec 24, 2013
Messages
252
Points
63
Location
Delhi
Durga Furniture is in Gurugram. In Delhi, there are numerous CNC shops in Kirti Nagar.


amangujral06

Member
Joined
Nov 8, 2012
Messages
65
Points
18
Location
delhi
Hi , i have been designing and manufacturing speaker cabinets(mostly hi-end) for a lot of my clients from past 6 years now. I am from south Delhi . If you want I can help you with your needs


Sanjeev Kumar

New Member
Joined
May 19, 2020
Messages
17
Points
3
Location
Delhi, india
Thanks for the info! Iread some BBC Audio tech papers, and in their testing, MDF was seen as one of the best. My friends confirm the same, be it DIY speaker enclosures or headphone cups.

BTW, I also saw that you made nice speakers from that Blaupunkt car speakers.

@Kumars - sorry for hacking the conversation.
