Specs of the Amplifier Section in detail

**Amplifier Section**

Rated Output Power

North American (FTC):

(FL, FR, C, SL, SR) 95 watts minimum continuous power per channel, 8 ohm loads, 2 channels driven at 1 kHz, with a maximum total harmonic distortion of 0.7%

(Subwoofer) 105 watts minimum continuous power per channel, 8 ohm loads, 1 channel driven at 80 kHz, with a maximum total harmonic distortion of 0.7%

(FL, FR, C, SL, SR)105 watts minimum continuous power

per channel, 6 ohm loads, 2 channels driven at 1 kHz, with a maximum total

harmonic distortion of 0.7%

(Subwoofer) 125 watts minimum continuous power

per channel, 6 ohm loads, 1 channel driven at 80 kHz, with a maximum total

harmonic distortion of 0.7%

European (IEC): 6 ch110 W at 6 ohms, 1 kHz, 1ch driven

Maximum Output Power

Asian (JEITA): 6 ch120 W at 6 ohms, 1 kHz, 1ch driven

Dynamic Power 180 W + 180 W (3?, Front)

140 W + 140 W (4?, Front)

95 W + 95 W (8?, Front)

THD (Total Harmonic Distortion) 0.9% (Power Rated)

Damping Factor 60 (Front, 1kHz, 8?)

Input Sensitivity and

Impedance 200 mV/ 47 k?

(LINE)

Output Level and

Impedance 200 mV/ 470?

(REC OUT)

Frequency Response 10 Hz50 kHz/ +1 dB-3 dB (Direct mode)

Tone Control 10 dB, 80 Hz (BASS)

10 dB, 20 kHz (TREBLE)

Signal to Noise Ratio 100 dB (LINE, IHF-A)

Speaker Impedance 6? 16?
